Key features:
DOOR LOCK:
The electrically operated door lock ensures complete safety, greater ease of use and reliable self-adjustment of the hatch.
BUILT-IN PRINTER:
A standard accessory that automatically prints out the entire procedure during the sterilisation process, thus providing a permanent record of each sterilisation cycle.
USB PORT:
Automatic digital recording of the cycle on a USB stick (optional).
USER-FRIENDLY INTERFACE:
Multilingual software with only four buttons for easy navigation to all sterilisation parameters. The LCD display shows current information about your sterilisation cycles and alerts you to errors or maintenance needs.
STERILISATION CHAMBER:
23 litres made of thick one-piece moulded steel. Available in AISI 304 (standard) and AISI 316 (on request).
WATER PURIFICATION SYSTEM:
Thanks to the integrated ROSI water purification system with three cartridges, your autoclave can be connected directly to your hospital's water supply (optional).
WATER QUALITY SENSOR:
Our sterilisers are further protected by the inclusion of a water quality sensor as standard. The water quality is therefore constantly monitored. The display informs the user of the quality of the water used for sterilisation.
Our units come standard with all the accessories you would expect, including tray holder, trays, removal tool, cleaning sponge and water connection, all included in the list price.
Technical specifications
| PHYSICAL CHARACTERISTICS | 23 litres | |
| Operating temperature | +5° +30° C | |
| Maximum working height above sea level | 2 000 м | |
| Maximum relative humidity at 30°C | 80% | |
| Maximum relative humidity at 40°C | 50% | |
| Overall dimensions (~) | 505 x 400 x 690 mm | |
| Max. weight with empty tanks | 58 kg | |
| Max. weight with full tanks + integrated system | 62 kg | |
| Maximum overall dimensions of open doors | 350 mm | |
| Colour | RAL9016 | |
| Material | Stainless steel AISI 304 and/or 316 / S235JR | |
| Noise at a distance of 1 m | 53.6 dBA | |
| Noise in front of the display | 62.2 dBA | |
ELECTRICAL CHARACTERISTICS
| Supply voltage | 230 V AC (+/-10 %) |
| Power | 2 400 W |
| Frequency | 50-60 Hz |
CAMERA CHARACTERISTICS
| Maximum working pressure | Relative 2.5 bar | |
| Maximum operating vacuum | Relative -0.90 bar | |
| Maximum operating temperature | 140°C | |
| Material | Stainless steel AISI 304 or 316 | |
| Overall dimensions: Diam. xD | 236 x 530 mm | |
CHARACTERISTICS OF THE CLEAN WATER TANK
| Maximum capacity | 4 litres | |
| Cycles in progress | ~5 | |
CHARACTERISTICS OF THE CONTAMINATED WATER TANK
| Maximum capacity | 4 litres | |
| Cycles in progress | ~5 | |
| Maximum temperature of the drained water | 75°C | |
CHARACTERISTICS OF THE BACTERIOLOGICAL FILTER
| Maximum diameter | 56 mm |
| Maximum permitted filter bandwidth | 0.03 microns |
| Characteristics for changing the filter | Every 250 cycles or every 3 months |
TRAY HOLDER CHARACTERISTICS
| Material | Stainless steel or anodised aluminium |
TRAY CHARACTERISTICS
| Material | Anodised aluminium or stainless steel |
